Housings And Enclosures Stainless Steel Cnc Machining Services Cnc Machined Parts Custom Machined Parts
At Xinbo Precision, we pride ourselves on the high quality of turned parts we produce. We appreciate your need for excellent surface finish especially on sealing faces and on surfaces that are visible to the end customer.
Whether your requirement is for the machining of aluminum, stainless steel, titanium, polycarbonate, acetal or medical plastics we can help you.
CNC Turning Parts We Made
CNC Machine Shops in Xinbo Precision have already produced many kinds of cnc turning parts in 13 years, our engineering team always provided useful solution to our customers to solve their difficult problems in making cnc turning parts.
CNC Machine shops in Xinbo Precision offer CNC turning service to help your business in the following ways:
•Production of Complex Parts and Components with Great Accuracy
•High Speed Production
•Cut down the Production Expenses and Boost Business profits
|Name||Custom Manufacturing Service, CNC Turning Parts.|
6061-T651 AMS 4117, 7049-T7351 AMS4200, 7050-T7451 AMS4050, 7075-T7351 AMS4124
E-Coating, Chemical Conversion, Laser Marking, Laser Engraving, Laser Etching
|Tolerance||ISO2768m, ISO2768f, 0.005mm.|
|Testing equipment||CMM; Tool Microscope; Automatic Height Gauge; Manual Height gauge; Dial Gauge; Screw Gauge; Plug Gauge; Micrometer; Marble Platform; Roughness Measurement|
|Processing||CNC milling, CNC machining, Grinding, EDM Wire Cutting, Sink EDM, Turning|
|File Formats||Solid Works, Pro/Engineer, AutoCAD(DXF,DWG), IGS,STP, PDF,TIF etc.|
|Service Project||Free Design Review(DFM report), Production And Technical Service.|
|Roughness||Ra0.4, Ra0.8, Ra1.6,Ra3.2, As machined.|
|CNC Milling||4 axis||200mm||BangBang||China||5||0.005mm|
|CNC Milling||5 axis||200mm||BangBang||China||1||0.005mm|
|Surface Grinder||PSGC-4080 AHR||400*800mm||Proth||Taiwan||2||0.002mm|
|High Speed Wire Cut||200*500mm||Jicheng||China||4||0.02mm|
|Medium Speed Wire Cut||DK7732C-C||320*400mm||Baoma||China||4||0.01mm|
|Laser Engrave Machine||G20||Cherrywoolf||China||1|
|Other equipment:Drill machine, Tapper, Polisher, EDM puncher, Ultrasonic cleaner, Sand blaster machine, Saw machine, Magnetic grinder.|
|CMM||CROMA 564||500*600*400mm||SERERN||Joint venture||2||0.003um|
|Film thickness gauge||AR932||0-1700um||Smartsensor||China||2||
What’s the CNC machining surface finishes
As machined (Ra 3.2μm / Ra 126μin)
This is our standard finish. Parts are machined and deburred, sharp edges are chamfered.
Smooth machining (Ra 1.6μm / Ra 63μin)
Smooth machining is like an ‘As machined’ finish but with slightly less evident machine marks. Parts are machined at a lower feed, no hand polishing is applied.
Fine machining (Ra 0.8μm / Ra 32μin)
Finer-looking machining obtained either through higher-precision machines, lower feeds, sharper tools, or a combination of all the above. Machining marks are less evident.
Polishing (Ra 0.8μm / Ra 32μin)
Parts are manually polished in multiple directions. Surface is smooth and slightly reflective.
